Sample Cooler SC105

Type: 2 (Larger, More Cost-Effective)
Coil Material: 316 Stainless Steel
Maximum Coil Pressure: 2,500 PSI @ 1,000 °F
Coil Surface Area: 3/8″ OD – 1.9 sq. ft.
Shell Material: Carbon Steel (CS)
Overall Height: 15.75 ″
Weight: 30 lbs

Connections (on top & bottom plates):
• Sample inlet (top plate): 1/4″ FNPT
• Cooling-water inlet (top plate): 3/8″ FNPT
• Cooling-water outlet (bottom plate): 3/8″ FNPT
• Cooled sample exits from the bottom fitting.

Typical Applications:
• High-temperature/high-pressure sampling (up to 1,000 °F, 2,500 PSI) with 3/8″ coil in a plate design.
• Labs or industrial sites that need corrosion-resistant coils but still want moderate surface area.
• Ideal for continuous steam or hot oil sampling with 1.9 sq. ft. of coil area.

Refer Manufacturer's Website.
