Sample Cooler SC108

Madden Engineered Products

$896.00
Unit price per
Save $64

Shipping calculated at checkout.

Type: 2 (Larger, More Cost-Effective)
Coil Material: 316 Stainless Steel
Maximum Coil Pressure: 4,925 PSI @ 1,000 °F
Coil Surface Area: 3/8″ OD – 1.9 sq. ft.
Shell Material: Carbon Steel (CS)
Overall Height: 15.75 ″
Weight: 30 lbs

Connections (on top & bottom plates):
• Sample inlet (top plate): 1/4″ FNPT
• Cooling-water inlet (top plate): 3/8″ FNPT
• Cooling-water outlet (bottom plate): 3/8″ FNPT
• Cooled sample exits from the bottom fitting.

Typical Applications:
• Compact, ultra-high pressure (4,925 PSI) sampling where you only need 1.9 sq. ft. of coil area.
• Good for installations with extremely tight height restrictions (under 16″ tall).
• Ideal for sampling superheated steam in small pilot plants or lab R&D environments.
